Half-wave rectifier with capacitor filter

By Anonymous

TikzMaker is a visual editor for TikZ. Open this figure on the canvas, change anything you like, and take the generated TikZ code straight to your LaTeX document.

Half-wave rectifier circuit with a diode, smoothing capacitor, and load resistor. The diode rectifies the AC input voltage \(v_{in}\), while capacitor \(C\) smooths the rectified waveform to produce the output voltage \(v_{out}\) across load resistor \(R_L\).

circuits · half-wave-rectifier · diode · capacitor-filter · rectifier-circuit · power-supply · load-resistor
