Sallen-Key low-pass and high-pass filters

By Anonymous

TikzMaker is a visual editor for TikZ. Open this figure on the canvas, change anything you like, and take the generated TikZ code straight to your LaTeX document.

Sallen-Key low-pass and high-pass filters

Comparison of unity-gain Sallen-Key second-order active filters. Circuit (a) shows the low-pass configuration using resistors \(R_1,R_2\) and capacitors \(C_1,C_2\), while circuit (b) shows the corresponding high-pass configuration using capacitors \(C_3,C_4\) and resistors \(R_3,R_4\).

circuits · sallen-key · active-filter · low-pass-filter · high-pass-filter · op-amp · second-order-filter
