Basic BJT current mirror

By Anonymous

TikzMaker is a visual editor for TikZ. Open this figure on the canvas, change anything you like, and take the generated TikZ code straight to your LaTeX document.

Basic two-transistor BJT current mirror with resistor-set reference current. Transistor \(Q_1\) is diode-connected and establishes the base-emitter voltage shared with matched transistor \(Q_2\), causing the output current \(I_{\mathrm{OUT}}\) to approximately mirror the reference current \(I_{\mathrm{REF}}\).

circuits · current-mirror · bjt · analog-circuit · current-source · bias-circuit · transistor-circuit
