Wilson BJT current mirror

By Anonymous

TikzMaker is a visual editor for TikZ. Open this figure on the canvas, change anything you like, and take the generated TikZ code straight to your LaTeX document.

Three-transistor Wilson current mirror with reference current \(I_{\mathrm{REF}}\) and output current \(I_{\mathrm{OUT}}\). The additional transistor provides feedback that improves current matching and increases output resistance compared with a basic two-transistor BJT current mirror.

circuits · wilson-current-mirror · current-mirror · bjt · analog-circuit · current-source · transistor-circuit
